SCR / SCR-S : The wire netting wire of the rolling and non-rolling process
Application
the abrasion resistance of the wire netting is improved the smooth bending work for the wire netting manufacturing is made possible with the material of the high intensity ductility
Type and Mechanical Properties of Products
| Product name | Title Diameter (mm) |
Standard diameter (mm) |
Tolerance (mm) |
Supe-relevation (mm) |
Nominal cross section (mm2) |
Unit weight (kg/m) |
Tensile strength (N/mm2) |
elongation percentage (%) |
|---|---|---|---|---|---|---|---|---|
| SCR / SCR-S |
5 | 5 | ±0.10 | ≤0.05 | 19.6 | 0.154 | 1420~1520 | 10.0 ↑ |
| 6 | 6 | 28.3 | 0.222 | 1029~1128 | ||||
| 7 | 7 | 38.5 | 0.302 | |||||
| 8 | 8 | 50.3 | 0.395 | |||||
| 9 | 9 | 63.6 | 0.499 | |||||
| 9.5 | 9.5 | 70.9 | 0.556 | |||||
| 10 | 10 | 78.5 | 0.617 | |||||
| 11 | 11 | 95 | 0.746 |
